Katool KT-X95 8,000 lb Full-Rise Scissor Lift for Tire and Brake Service
Katool KT-X95 8,000 lb Full-Rise Scissor Lift for Tire and Brake Service is backordered and will ship as soon as it is back in stock.
Your payment information is encrypted and never stored
We're Here When You Need Us
We're Available When You Need Us. Give Us A Call or Email.
Katool KT-X95 8,000 lb Full-Rise Scissor Lift for Tire and Brake Se...
If you want full-rise lifting without sacrificing a clean shop floor, the Katool KT-X95 is built exactly for that. This flush-mount full-rise scissor lift gives you the height and access of larger lifts while staying low-profile when not in use—perfect for shops that care about both performance and workspace efficiency.
With an 8,000 lb capacity and over 72 inches of lift height, the KT-X95 allows technicians to comfortably work under vehicles without obstruction. It’s designed for real shop conditions, combining smooth hydraulic operation with safety-focused features like pneumatic lock release and low-voltage controls.
Whether you’re handling routine maintenance or more involved repair work, this lift delivers the balance of strength, safety, and space-saving design that modern shops need.
Key Features & Benefits
- 8,000 lb Lifting Capacity – Handles cars, SUVs, and light trucks with ease
- Full-Rise Height (72.3") – Provides comfortable undercar access for detailed work
- Flush-Mount Design – Keeps your shop floor clear when the lift is lowered
- Pneumatic Safety Lock Release – Reliable locking system with air-assisted control
- 24V Safe Control System – Low-voltage operation for added safety
- Height Limit Protection – Prevents over-travel during lifting cycles
- Drive-Up Ramp Lock Design – Supports longer wheelbases with added stability
- Aluminum Motor with Cooling Fan – Helps prevent overheating during extended use
- Self-Lubricating Bushings – Reduces maintenance and ensures smooth operation
- Composite Rubber Lifting Blocks – Protects vehicle contact points
- CE Certified – Tested to 115% dynamic and 150% static load standards
- Full Access Without Posts – Clean undercar workspace for efficient repairs
- Space-Saving Design – Ideal for shops that want an open, organized floor
- Built for Daily Use – Reliable performance in busy shop environments
| Specifications | Details |
|---|---|
| Model | KT-X95 |
| Product Type | Full-Rise Flush-Mount Scissor Lift |
| Lifting Capacity | 8,000 lbs (3,500 kg) |
| Max Lifting Height | 72.3" (1,836 mm) |
| Lifting Time | ≤ 50 seconds |
| Platform Length | 58.9" (1,496 mm) |
| Platform Width | 24.4" (620 mm) |
| Motor Power | 2.2 kW |
| Rated Oil Pressure | 20 MPa |
| Air Pressure Requirement | 6–8 kgf/cm² (≈ 85–115 psi) |
| Control Voltage | 24V |
| Safety Features | Height limit switch, pneumatic locking system |
| Design | Flush-mount with drive-up ramps and lock |
| Certifications | CE Certified (115% dynamic / 150% static tested) |
What's Included
- Lift system
- Composite rubber lifting blocks
- Control system
