AMGO DX-12A Scissor Alignment Lift 12,000 lb Capacity
The AMGO DX-12A is a high-capacity double scissor alignment lift designed for professional shops that demand versatility and strength. With a 12,000 lb lifting capacity and auxiliary lifting platforms, it allows full-wheel access for alignment, brake, suspension, and tire service — all in one system.
Key Features & Benefits
- 12,000 lb lifting capacity for cars, vans, and light trucks
- Double scissor design for enhanced stability and lifting power
- Built-in auxiliary lifting platforms for full wheel-free service
- Alignment-ready configuration for precision shop work
- Heavy-duty X-style steel structure for long-term durability
- Large non-slip diamond platforms for secure vehicle positioning
- Dual synchronized hydraulic cylinders maintain level lifting
- Integrated photocell system prevents platform imbalance
- Hydraulic cylinders equipped with hose burst protection valves
- Mechanical safety locks with air-release system
- Electro-hydraulic power system with control unit
- Automatic safety stop system included
Why This Lift Stands Out
What separates the DX-12A from standard alignment lifts is the integrated auxiliary scissor system, allowing technicians to lift the entire vehicle and then raise individual wheels for service. That means you're not just doing alignments — you're handling full undercarriage work without switching equipment.
Installation & Requirements
- Minimum 4" concrete thickness (3,000 PSI) required
- Surface or flush-mount installation options available
- 220V power required (2.0 HP motor minimum)
- Air supply required (approx. 0.8 MPa operating pressure)
- Indoor installation only
- Professional installation strongly recommended
What's Included
- AMGO DX-12A Alignment Scissor Lift
- Dual platform system with auxiliary lifting scissors
- Hydraulic power unit and control cabinet
- Drive-on ramps and runway platforms
- Hydraulic hoses, air lines, and fittings
- Installation hardware and manual
| Specifications | Details |
|---|---|
| Model | DX-12A |
| Lift Type | Double Scissor Alignment Lift |
| Lifting Capacity | 12,000 lbs |
| Lifting Time | 64 seconds |
| Max Lifting Height | 73 5/8" |
| Minimum Height | 12 5/8" |
| Overall Length (With Ramps) | 256" |
| Overall Width | 86 1/4" |
| Runway Width | 24 5/8" |
| Distance Between Platforms | 37" |
| Gross Weight | 5,706 lbs |
| Motor | 2.0 HP |
| Structural Warranty | 5 Years |
| Hydraulic Components Warranty | 2 Years |
| Electrical Components Warranty | 1 Year |
| Shipping | Free freight shipping — continental U.S. |
| Processing Time | 1–2 business days (in-stock items) |
| Estimated Delivery | 5–10 business days |
