MechMaxx 86" Heavy Duty Offset Verge Flail Mower with CMR Gearbox, 90–120HP, Model VBM86

Trimming banks, roadsides, ditches, and shorelines can be demanding work—but the MechMaxx VBM86 is built to handle it with ease. Designed for professional land maintenance, this heavy-duty hydraulic flail mower delivers powerful cutting performance, extended reach, and reliable durability in tough environments.

Powered by a robust Italian CMR gearbox, this mower delivers consistent power to tackle dense grass, brush, and overgrowth. Equipped with heavy-duty forged hammer blades, it efficiently cuts and mulches material in a single pass, leaving behind finely shredded clippings that naturally decompose and help enrich the soil. An adjustable rear roller ensures precise cutting height control, while the openable rear cover allows for quick maintenance and easy clearing of debris.

Key Features & Benefits

• 86-Inch Wide Cutting Deck – covers large areas quickly, ideal for fields, ditches, and roadside maintenance
• Heavy-Duty Hammer Blades (20 Total) – aggressive mulching performance for thick vegetation and brush
• Hydraulic Tilt Function (90° Up / 55° Down) – perfect for slopes, embankments, and vertical trimming
• Hydraulic Side Shift & Offset Reach – extend beyond the tractor to reach hard-to-access areas
• Adjustable Rear Roller – provides consistent, even cutting height across uneven terrain
• Compatible with 90–120 HP tractors; operates at 540 RPM PTO for optimal efficiency
• Capable of cutting and mulching material up to 6 inches (conditions dependent)
• CMR Gearbox (Italy) – delivers smooth, reliable power transmission under heavy load
• SKF Shaft Bearings (Sweden) – engineered for high-load applications, runs cooler, quieter, and longer
• External Rotor Bearings – simplifies maintenance and improves serviceability
• Dynamically Balanced Rotor – reduces vibration for smoother operation
• Spring-Loaded Anti-Collision System – absorbs impact and protects the mower from obstacles
• Openable Rear Cover – quick access for blade replacement and debris removal
• Category 2, 3-Point Hitch – built for larger tractors and heavy-duty applications
• Included PTO Shaft (1-3/8" Z6) – compatible with most tractors; driveline length 73"–126"
• Tilt Range: 90° Up / 55° Down; hydraulic offset for extended reach
• Designed for ditch banks, slopes, and roadside mowing

Important Delivery Note

Liftgate delivery is not available for this unit. You will need a forklift, tractor, or unloading equipment at delivery due to size and weight.

Documents

• Product Manual
