Katool KT-H120D 12,000 lb 2-Post Car Lift with Direct-Drive Hydraulics
SKU: KT-H120D
We're Here When You Need Us
We're Available When You Need Us. Give Us A Call or Email.
Pairs well with
The Katool KT-H120D is a 12,000 lb two-post lift configured with a clear-floor layout and asymmetric arms to support vehicle service operations across a range of applications. Its design allows open access beneath the vehicle while maintaining balanced lifting for cars, trucks, and SUVs.
With a lifting height in the 72–74 inch range and a low pad height, the KT-H120D accommodates both standard and lower-clearance vehicles. The hydraulic lifting system provides controlled operation, while the mechanical locking system supports secure positioning during service work.
Constructed with heavy-duty steel components, this lift is intended for repeated use in environments requiring consistent lifting performance.
Key Features & Benefits
- 12,000 lb Lifting Capacity – Supports cars, trucks, and SUVs
- Clear-Floor Design – Open workspace between columns
- Asymmetric Arm Configuration – Improved vehicle positioning and access
- Mechanical Locking System – Multiple lock positions for secure holding
- Single-Point Lock Release – Centralized lowering control
- Low Pad Height (~4.5") – Compatible with lower-clearance vehicles
- Adjustable Lift Arms – Supports different vehicle lift points
- Hydraulic Operation – Controlled lifting and lowering
- Heavy-Duty Steel Construction – Built for repeated use
- Provides open access for undercar service work
- Suitable for general automotive repair and maintenance
- Designed for consistent operation in shop environments
| Specifications | Details |
|---|---|
| Model | KT-H120D |
| Product Type | Two-Post Vehicle Lift |
| Lifting Capacity | 12,000 lbs (5,443 kg) |
| Max Lifting Height | ~72–74 in |
| Minimum Pad Height | ~4.5 in |
| Overall Height | ~144 in |
| Drive-Thru Clearance | ~94 in |
| Motor Power | ~2–3 HP (varies by configuration) |
| Power Requirement | 220V / 60Hz / Single Phase |
| Locking System | Multiple mechanical lock positions |
| Safety Features | Dual locking system, cable equalization, automatic shut-off |
| Construction | Heavy-duty structural steel |
| Concrete Thickness (Min) | 5.9 in |
| Concrete Strength (Min) | 3,000 PSI |
Documents
Operation Video
Installation Video
