AMGO BP-10 2-Post Car Lift 10,000 lb Adjustable Width
Authorized Dealer
SKU: BP-10
We're Here When You Need Us
We're Available Mon–Fri: 9am – 5pm EST
Pairs well with
The AMGO BP-10 is a commercial-grade base plate two-post lift designed for shops and garages that need strong lifting performance without requiring high ceilings. Built with a floorplate design, this model is ideal for tighter spaces while still handling a wide range of vehicles — from compact cars to long-wheelbase trucks. With symmetric 3-stage arms, dual safety locks, and adjustable width settings, the BP-10 delivers dependable performance, flexibility, and long-term durability.
Key Features & Benefits
- 10,000 lb lifting capacity for cars, SUVs, and light trucks
- Base plate (floorplate) design – ideal for low ceiling garages
- 4 symmetric 3-stage telescoping arms for broad vehicle compatibility
- Single-point safety lock release unlocks both columns from one side
- Dual safety lock system for added protection
- Automatic arm restraints keep arms secure during lifting
- Self-lubricating UHMW polyethylene sliders reduce wear
- Aero sync cables ensure smooth, even lifting
- Includes toe guards and tool trays
- Double-screw rubber pads with 3" extensions included
Why Choose a Base Plate Lift?
- No overhead bar — fits lower ceiling heights
- Open top design — better for garages with obstructions
- Strong floorplate connection for stability
Installation Requirements
- Concrete thickness: Minimum 4 inches
- Concrete strength: 3,000 PSI
- Indoor use only
- Must be installed on level concrete (no asphalt)
- Minimum ceiling height: ~112 inches (~9.3 ft)
What's Included
- Dual hydraulic cylinder system
- Chain-driven lifting system
- 4 symmetric 3-stage arms
- Rubber pads and 3" extensions
- Power unit
- Sync cables and safety system
- Tool trays and toe guards
| Specifications | Details |
|---|---|
| Model | BP-10 |
| Lift Type | Base Plate Two-Post Lift |
| Lifting Capacity | 10,000 lbs |
| Lifting Time | 62 seconds |
| Max Lifting Height (Without Adapters) | ~76 3/8" – 78 1/4" |
| Max Lifting Height (With Adapters) | ~79 3/8" – 81 1/4" |
| Max Lock Height | Up to ~79 11/16" |
| Overall Height | 111 7/8" |
| Overall Width | 139 1/8" or 145 1/16" |
| Drive-Thru Clearance | 100 13/16" – 106 11/16" |
| Width Between Columns | 112 3/16" or 118 1/8" |
| Minimum Pad Height | 3 9/16" |
| Gross Weight | ~1,697 lbs |
| Motor | 2.0 HP, Single Phase |
